60SP-ELT
60SP-ELT (for Electrode Hobbing)
| 60SP-ELT | |
|---|---|
| Hob head swivel angle | ±45° |
| Maximum workpiece diameter (mm) |
60(120) |
| Maximum hobbed length (mm) |
150 |
| Maximum work length (mm) |
200 |
| Maximum module (m) |
2.0 |
| Number of teeth(Z) | 3～999 |
| Maximum hob cutter Hob arbor diameter |
φ50 (φ10) X 60mm |
| Hob speed （min-1） |
200～2,000 |
| Feed rate (mm/min) |
0.1～500 |
| Hob shift travel (mm) |
100 |
| Work spindle (KW) |
6.0 |
| Total KVA | 18 |
| Floor space × height (mm) |
2000×2000×2000 |
| Weight (kgf) |
3500 |
Features
Most suitable for cutting high precision electrode of gear mold.
Capable continuous operation automatically by applying horizontal dislocation hobbing of two locations of gear part for rough and finish hobbings.
Capable high precision hobbing using built-in type motors for hob spindle and work spindle.
Possible to easy input the micro changes required for cutting high precision electrodes using conversational type CRT display.
